Description
GigaWatt PowerControl : Power Conditionner
PowerControl conditioner is an extension of the concept used in PowerPrime. This model also uses the solutions known from the higher PC series power conditioners. The device is equipped with 12 outlets, making it comparable in functionality to the flagship PC-4 EVO+. The standard equipment includes voltage display with switch, and DC Blocker. Like all GigaWatt power conditioners, the PowerControl is available with front panels in black and silver.
The main features :
– Twelve high quality, silver plated proprietary power outlets to keep ZERO contact resistance
– New LED Voltmeter display, with switch OFF button. White colour as a standard, 9 custom colors on request (extra charge)
– Compact chassis depth to reduce footprint in space restricted applications
– Anti-vibration, GigaWatt aluminum feet with softpads to absorb vibrations
– Top cover damped with a bitumen-polymer composite mat
– Ground/Polarity fault detection indicator, to avoid wrong polarity or faulty grounding of the unit
– Filtering architecture with special GigaWatt Audio Grade EMI Suppression Capacitors to keep ultimate filtering performance
– Massive, outlets distribution rails, 30 QMM polished copper (OFHC 10100, 99.995%) to keep stable power distribution for outlets in star connection topology
– Internal wiring – OFC 4,0 QMM by GigaWatt Powerlink to keep ultimate conductor transmission
– Dual layer PCB, silver-plated copper with ultra wide traces to reduce power losses
– RLC type filtering block with HF (High Flux) core filter to allow maximum interference damping
– Ultimate Surge protection based on plasma spark-gaps and UltraMOV varistors
– DC Offset Blocker on board to eliminate unwanted DC component of the power grid
– Advanced switch from Carling Technologies to allow no compromise switching
– Internal electric construction to allow load up to 100A peak
– Non-magnetic screws, at points of current flow, to avoid degradation of the electric field
– Enhanced buffer circuit with GigaWatt Audio Grade compensation battery for power factor improve and for maximum impulse response
– Special internal sandwich base to prevent the transmission of resonant vibrations from the chassis to the filter elements
– Internal elastomer Shock dampers that prevents transmission of external vibrations to filter elements
– IEC C20 inlet allowing for better contact and power flow
– Ground lug for turtables, cables (ect) additional earthing
– PowerSync PLUS power cord 1,5 m. as a standard (other cables optionally)
This product is covered by an insurance policy for the connected equipment, with a total insurance value of 1000000 PLN. The insurance is valid only in the European Union member states territory.
Specifications :
Available socket types: EU (Schuko), US (Nema 5-20R), AU (AS/NZS 3112)
Line voltage: 220-240 VAC 50/60 Hz, 110-120 VAC 50/60 Hz
Maximum output power : 3 680 W
Maximum current load: 16 A
Absorbed impulse current: 13 000 A
Dimensions: 440 x 310 x 165 mm
Gross weight: 15,7 kg (with PowerSync Plus cable)Control
