Description
Ideon Ayazi mk2 DAC : DAC
he Ayazi mk2 DAC is designed and fine-tuned specifically to reveal the musical magic encoded in the numbers, that are stored within the digital medium. Sound reproduction with exceptionally broad dynamic range, ultra-low distortion and low noise, accurate sound stage, and musical congruity.
We used the device in many different high-end systems and set-ups as it is intended to be the jack of all trades for digital-to-analogue conversion, to be used anytime, anywhere…
A high-performance DAC
No frills construction: solid and functional, the Ayazi as one reviewer put it, “probably sets the sonic performance benchmark for DACs costing double or more its asking price”, encompassing what we started out to do: to offer the experience of the musical event, a sound you wont believe for its price. With the Ayazi, style follows function and budget. The result: when it comes to DACs the Ayazi is the affordable reference!
Specifications :
DIGITAL INPUTS | USB type 2 and above, SPDI/F |
OUTPUT FULL SCALE | 2.0V RMS |
FREQUENCY RESPONSE | 10Hz-25kHz (+/- 0.5dB) |
SNR (DC to 20kHz) | >112dB |
CROSSTALK | -110dB |
SNR (A WEIGHTED 20HZ-20KHZ) | >130dB on all outputs |
THD+N (1kHz FS 96 kS/s) | <0.002%E |
USB INPUT | Transfer mode: Asynchronous (dual clock) Device class: Type 2 or above Bit depth: 32 bit Sampling rates: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz |
SPDIF / COAXIAL INPUT | Bit depth: 24 bit Sampling rates: 44.1, 48, 96, 192 kHz |
CONTROLS | On/off switch, led indicator USB / SPDI/F input, sync led indicator |
POWER REQUIREMENTS | 230 / 110 V AC, 1A, 20W max |
OPERATING TEMPERATURE | 0-35˚ C |
RELATIVE HUMIDITY | 5-95% non-condensing |
OUTPUT | Stereo unbalanced impedance: 250 Ω |
DIMENSIONS (W X H X D) | 370 X 75 X 175 mm (14.5 X 2.9 X 6.8 in) |
WEIGHT | 7 kg (~ 15.4 lbs) |
