Description
Silent Angel Munich MU : Streamer Player
Munich MU is High-End’s premier network streamer, advancing the formidable capabilities of the iconic M1. The development of a sophisticated, double-layer chassis design inspired by our State-of-the-Art Bonn NX and Genesis GX combined with meticulous fine-tuning and relentless testing, complemented by specialized system software, every effort has been devoted to creating an unmatched digital audio experience.
Specifications :
Available Color | Black, Silver |
Ethernet | 1 GbE RJ45 x 1 |
Management System | VitOS Orbiter (for iOS, Android) |
LED Indicator | Red, green, and blue lights flash in sequence > System booting Blue light remains steady > Startup process completed Blue light stays steady > Standby mode Red light blinks > Mute mode Green light blinks > PCM output format Blue light blinks > DSD output format |
Music Format | AAC, M4A, MP3, OGG, FLAC, WAV, ALAC, DSD (DSF, DFF), WAV64, AIFF, CUE Files, WMA, APE |
Digital Outputs | AES/EBU port x 1 I2S port x 1* Coxial port x 1 – Supports up to PCM 384KHz and DSD 5.6M (DSD128)* I2S output signal is not compatible with Holo Audio’s DAC |
USB Audio | USB Audio port x 1 – Supports up to PCM 768KHz and DSD 11.2M (DSD256) |
Analog Output | Balanced XLR Outputs, Unbalanced RCA (L+R) Outputs |
USB external storage | USB 3.0 x 2 USB 2.0 x 1 |
External Clock Input Port | 10MHz x 1 |
CPU | Dual-core Cortex-72, frequency 1.8GHz + Quad-core Cortex-A53, frequency 1.4GHz |
RAM | Low-Noise 4GB |
Firmware and System | High-Speed 32GB |
SSD Storage | M.2 NVMe SSD (2280) Reserved, Up to 4TB, This product does not include a hard drive. |
Chassis Material | Aluminum alloy material sandblasted anodized appearance, Double-layer casing isolation design. |
Dimensions | 360(W)*73(H)*220(D)mm 12.45(W)*1.95(H)*6.97(D)inch |
Weight | 4.65KG (10.25 lb) |
Package | Player, Power cord, Network cable, Quick install guide, Warranty card. |
