Description
Bel Canto eOne DAC 2.8 : DAC/Preamp
Incredible audio performance, features, and flexibility, the DAC2.8 is musically open, detailed, and natural sounding.
- Class Leading 124dB Dynamic Range
- 24 Bit Volume Control
- 24/192 Asynchronous USB2.0
- Analogue Input
- 5 Asynchronous Digital Inputs
- High Current Headphone Output Driver
- Remote Control
- Available in Black or Silver Faceplate
- MAC USB 2.0 compatibility and custom Windows USB 2.0 driver
Specifications
DIGITAL SECTION:
- Maximum Data Input Rate:
- 24bit Data at 192KS/s: AES XLR, SPDIF BNC/RCA, TOSLINK, USB
- Master Clock noise: 0.07 picoseconds RMS
ANALOG 24/192 DAC SECTION:
- Maximum Output: 4.5Vrms balanced XLR, 2.25Vrms RCA
- Output Impedance: 200 ohms balanced XLR, 100 ohms RCA
- Frequency Response: 20Hz-20KHz, +/- 0.5dB
- THD+N: <0.001%, 1KHz
- Output Noise: 3.3uVrms A-weighted 20Hz-20KHz
- Dynamic Range: 124dB A-weighted 20Hz-20KHz
ANALOG 24/192 ADC SECTION:
- Maximum Input: 2.5 Vrms RCA
- Input Impedance: 12K ohms RCA
- THD+N: 0.003%, 2.5Vrms in, 1KHz
- Dynamic Range: 110dB, A-weighted 20Hz-20KHz
HEADPHONE SECTION:
- Headphone Output Current and Voltage Level: 4.5Vrms, 300mA
- THD+N: 0.0015% 1KHz
- Output Noise: 3.3uVrms, A-weighted 20Hz-20KHz
GENERAL:
- Power Usage On: 8W
- Power Usage Off: 0.0W
- Power Requirement: 100-120VAC, 220-240VAC 50/60 Hz
- Dimensions: 8.5″ W x 12.5″ D x 3.5″ H (216 mm x 318 mm x 88 mm)
- Weight: 14lbs. (6.5 kg)
